System Control Panel
The generator control board, located inside the generator,
under the roof, is shown below. Brief descriptions of the
controls used during installation are:
A
- Menu/Programming Navigation Buttons —See
Menu section for details
B
- Mini USB Port—AuthorizedDealerServiceUseOnly.
C
- Generator Operation Control Buttons —
• “AUTO” Normal operating position. Press and hold
button to put unit into Automatic mode. In Automatic
mode, if a utility power outage is sensed, the system
will start the generator. When utility power is restored,
auto lets the engine stabilize internal temperatures,
shutsothegenerator,andwaitsforthenextutility
outage.
• “OFF” Turnsorunninggenerator,preventsunitfrom
starting, and resets any detected service codes.
OFF must be pressed and held for more than 5 seconds in
order to reset service code memory.
•“MANUAL” Used to manually start the generator.
D
– 15 Amp Fuse—ProtectsthehomegeneratorDC
control circuits. If the fuse has ‘blown’ (melted open)
or was removed, the engine cannot crank or start.
Replace the fuse using only an identical ATO 15A fuse.
One spare fuse is supplied with the unit.
E
- Cover—Thisprotectivecovermustberemovedto
access the fuse and the USB port.
F
- Digital Display—Displaysgeneratormode,menu
options, service codes, and service engine indicators
More information may be found in Controls in the
operator’s manual.
A
B
C
D
F
E
