Part No. Descri
p
tionRef.
Parts List -
Enclosure
Footnotes:
Part No. Descri
p
tionRef.
BASE 1 B314636GS
PANEL, End, Left 2 AL314645GS
SUPPORT, Rail 3 314638GS
INSULATION 4 315447GS
PANEL, Front 5 318242GS
* WASHER, External Lock, M66-----
* CAPSCREW, Hex Head, 1/4-20 x 3/47-----
LATCH 8 314619GS
BADGE 9 207095GS
BOLT 10 B4300GS
LATCH, Arm 11 315443GS
INSULATION 12 315453GS
PANEL, End, Right 13 AL314694GS
INSULATION 14 315452GS
ROOF 15 318232GS
DECAL SHEET, Warnings 16 318449GS
DECAL 17 317921GS
* NUT, Flange, 1/4-2018 -----
SCREW 19 311644GS
TRIM 20 316954GS
PANEL, Back 21 AL314651GS
PANEL, Corner 22 AL314681GS
SUPPORT-RAIL 23 314652GS
BRACKET, Roof Support 24 314647GS
PANEL, Corner 25 AL314644GS
BRACE 26 314646GS
SPRING 27 314649GS
BRACE 28 314672GS
BRACKET, Roof Support 29 314679GS
SUPPORT 30 314625GS
PANEL, Intake, Alternator 31 314684GS
CLIP 32 314661GS
SEAL 33 314682GS
SEAL 34 311692GS
* WASHER, Flat, M835 -----
DUCT, Alternator 36 314626GS
SEAL 37 315454GS
PANEL, Muffler 38 314624GS
PANEL, Muffler, Bottom 39 314620GS
DECAL SHEET, Warnings 40 318449GS
PANEL, Muffler, Top 41 314621GS
DEFLECTOR, Muffler 42 314699GS
DEFLECTOR, Exhaust 43 317254GS
SEAL 44 316951GS
PANEL, Intake, Engine 45 314683GS
TRIM 46 316202GS
DECAL 47 205392GS
PLUG 48 198460GS
SCREW 49 194561GS
SCREEN 50 316194GS
SUPPORT 51 315444GS
KEY, Latch 52
31
4290GS
PLUG, Roof -- 316193GS
* Items without part numbers are common fasteners and are available at your local hardware store.
1
The above parts group applies to the following Mfg. Nos.:
Briggs & Stratton Power Products Group, LLC
Copyright © by Briggs & Stratton Corporation
Milwaukee, WI, USA. All rights reserved
2013
040334-00 - 20,000 Watt Home Standby Generator (GE)
318955IPL No.
