D1 Spas Series – General Specifications – 2004 Chairman
Note: Subject to change without notice.
Doc-869 Rev – A Rev Date: 11/7/03 2004, Chairman Page 1 of 5
General Domestic (60Hz) Part # Export (50Hz) Part #
Shape Square Square
Shell Material Ultralife™ / Granitex™ Ultralife™ / Granitex™
Height 35 ½ in. 90 cm
Width 91 ½ in. 232 cm
Length 91 ½ in. 232 cm
Corner Radii 16 in. 41 cm
Seating Capacity 6 6
Water Capacity 400 Gallons 1514 Liters
Dry Weight 685 lbs 311 kg
Full Weight 4017 lbs 1822 kg
Skirt Material Wood or Synthetic Wood or Synthetic
Poly Floor Yes Yes
Water System
Pump Brand HydraMax by Sta-Rite Aqua-flo
Motor Size 4.0 HP 2.0 HP
# Pumps/Speed Two / Dual 01562-23A/B Two / single 01562-29A/B
Plumbing Systems 4 4
Pump Returns 4 01510-559 4 01510-559G
Typhoon Jets 1 01510-436 1 01510-436G
VCR Jet® - Air
Adjustable/Directional
9 01510-418 9 01510-418G
VCR Jet® - Rotator
13 01510-415 13 01510-415G
VCR Jet® - Mini Rotator
2 01510-445 2 01510-445G
VCR Jet® - Mini Directional
6 01510-444 6 01510-444G
VCR Jet® - Mini Directional in NFJ
8 01510-595 8 01510-595G
VCR Jet® - Euro Directional
0
0
Ozone Jet 1 01510-201 1 01510-201G
Heater Return Jet 1 01510-275 1 01510-275G
Total Jets 41 41
Filters/Coverage 2 / 75 sq. ft. (2) 01561-00 2 / 6.97 sq. meters (2) 01561-00
Water Treatment System Ultra Pure™ Ultra Pure™
Gate Valves 4 01522-30 4 01522-30
Diverter Valves 2 01522-50 2 01522-50G
Floor Drains 1 01510-231 1 01510-231G
Skimmer 8” Weir 01510-137 20 cm Weir 01510-137G
Electrical System
Voltage 240 240
Amperage 50/40/30 1X16 / 2X16 / 1X32
Heater FastFlo 2.7,4.0,5.5 kW 01781-20 FastFlo 2.9 kW 01781-20
Thermostat Electronic Electronic
Light 1 with optional LED 01512-003 (O) 1 with optional LED 01512-003 (O)
Control System MSPA-MP-D12 01710-1008 MSPA-MP-D11-CE 01710-1008E
Upper Control Scrolling Message Center 01560-1010 Scrolling Message Center 01560-1010
Auxiliary Upper Control Yes Yes
Programmable Yes Yes
Special Features
Dynamic Massage Sequencer w/
control panel
No
No
NeckFlex® Jet Pillows
2 01510-598 2 01510-598
Headrest Pillows 1 01510-593 1 01510-593
Cup Holders 3 3
Tactile Therapy Foot & hand Foot & hand
