Note: 1. Subject to change without notice.
Specification, Arena
Doc-1516 Rev -C
Rev Date: 8/24/07
Arena Specifications
Dimension One Spas
Shape Round
Seating Capacity 7+
Shell Material Ultralife™ / Granitex™
Dimensions 87" Diameter x 36" H / (221cm Diameter x 91cm H)
Corner Radii n/a
Water Capacity 340 Gallons (1287 Liters)
Dry Weight 560 lbs (254 kg)
Shipping Weight Domestic 560 lbs (254 kg) - Export 610 lbs (277 kg)
Full Weight 3395 lbs (1540 kg)
Skirt Material Wood
Poly Floor Yes
Water Treatment System Crystal Zone™
Plumbing Systems 2
Filters/Coverage 1 / 75 sq. ft.
Gate Valves 2
VCR Jet® - Air Adjustable/Directional 2
VCR Jet® - Rotator 6
VCR Jet® - Dual Rotator 0
VCR Jet® - Multi Port Spinner 0
VCR Jet® - Mini Rotator 2
VCR Jet® - Mini Directional 2
VCR Jet® - Euro Directional 0
VCR Jet® - Euro Rotator 0
VCR Jet® - Mini Directional in NFJ 0
Typhoon Jet 2
Ozone Jet 1
Heater Return Jet 1
Pump Returns 2
Diverter Valves 1
Floor Drains 1
Skimmer 8” Weir
Dynamic Massage Sequencer w/ control panel
No
NeckFlex® Jet Pillows 0
Headrest Pillows 0
Stereo system not available
Water Feature n/a
Water Feature Volume control n/a
Cup Holders 0
Tactile Therapy Floor pedastal
Pump Information Domestic (60Hz) Export (50Hz)
Motor Size – Peak (Continuous) HP 4.0 (2.5) Hp 3.6 (2.0) HP
Jet Pumps # of Pumps/Speed One / Dual One / single
Circulation pump 1 1
Fountain pump n/a n/a
Electrical System Domestic (60Hz) Export (50Hz)
Voltage 240 240
Amperage 40/30 1X16 / 2X16 / 1X32
Heater FastFlo 2.7,4.0,5.5 kW FastFlo 2.9 kW
Thermostat Electronic Electronic
Light 1 with optional LED Multi color LED
Control System MSPA-MP-D12 MSPA-MP-D11-CE
Upper Control (programmable) MSPA-1 midrange UCP MSPA-1 midrange UCP
Auxiliary Upper Control No No
General
Water System
Special Features
