Dacor RV36 Blower User Manual



PLANNING
GUIDE
Web: http://www.dacor.com
Corporate Phone: 800-793-0093
Specifications are subject to change without notice.
See installation instructions for additional details.
30”, 36”, 46” Wide,
Raised Vent
RV30, RV36, RV46
L65339 rev C
8.2
RV
22 1/4" (565mm)
Cooktop and RV cutout
4 1/4"
(108mm)
18"
(457mm)
15 1/8"
(384mm)
DUCT
C
L
5 1/4"
(133mm)
13 1/2" (343mm)
C
L
AIR
CABP3
Drawer/Tray
1 1/2"
(38mm)
Max.
“A”
3 1/4" (83mm) x
10" (254mm)
4 3/4" (121mm)
Typical platform height
23 1/2" (597mm) Min.
Face of cabinet
Face of cabinet
36"
(914mm)
Typical
counter height
All Dacor Preference™
& Millennia™ Cooktops
Adjustable
support leg
Shelf
20 1/2"
(521mm) Max.
Drawer/Tray
Cabinet
back
1/2"x2"
Channel
All Dacor
Preference™
& Millennia™
Cooktops
3"
(76mm)
1/4" (6mm) Min. flat area
3/4" (19mm) Max. Backsplash thickness
Wall board
Stud wall
RV
2 3/8"
(60mm)
3 1/4" x 10"
Exhaust duct
CABP3 CABINET BLOWER INSTALLATION
(Cutaway Side View)
Models “A” Min. Clearance
Electric Cooktops 2” (51mm)
Gas Cooktops 1/4” (6mm)
1/2091605
TOP CAP DIMENSIONS
13/16
(21mm)
7/16
(11mm)
1 13/16 (46mm)
