IRIS
®
5" ELEMENTS
938
COOPER LIGHTING
5" SHOWER/ LENSED ELEMENTS
E5LUNA Wet Location Blown Veined Glass
Module/Lamp: P5 with M42T Module: 32W Triple Compact Fluorescent
PN5 with M42T Module: 32W Triple Compact Fluorescent
P5 with M32TLUTRON Module: 26/32W Triple Compact Fluorescent
PN5 with M32TLUTRON Module: 26/32W Triple Compact Fluorescent
P5 with M42T277 Module: 26/32W Triple Compact Fluoescent
An Emergency version is available for compact fluorescent units.
P5 with M120 Module: 100W A19, 75W BT15
PN5 with M120 Module: 100W A19, 75W BT15
Dimensions: OD: 7 1/4" (184mm)
E5SR Wet Location Regressed Lens
Add Cone Color and Flange style
Module/Lamp: P5 with M42T Module: 32W Triple Compact Fluorescent Lamp
PN5 with M42T Module: 32W Triple Compact Fluorescent Lamp
P5 with M32TLUTRON Module: 26/32W Triple Compact Fluorescent Lamp
PN5 with M32TLUTRON Module: 26/32W Triple Compact Fluorescent Lamp
P5 with M42T277 Module: 26/32W Triple Compact Fluoescent Lamp
An Emergency version is available for compact fluorescent units.
P5 with M120 Module: 75W A19, 75W BT15, 60W MB19
PN5 with M120 Module: 100W A19, 75W BT15, 75W MB19
Dimensions: OD: 6 1/4" (159mm) Aperture: 5 1/4" (133mm)
E5QT4 Wet Location 50° Cutoff Reflector
Add Cone Color and Flange style
Module/Lamp: P5 with MQT4 Module: Q100T4/MC
PN5 with MQT4 Module: Q100T4/MC
Dimensions: OD: 6 1/4" (159mm) Aperture: 5 1/4" (133mm)
Cone Finishes:
C = Clear Specular Alzak
H = Haze Clear Semi-Specular Alzak
G = Champagne Gold Specular Alzak
B = Specular Black Alzak
WMH = Warm Haze Semi-specular Alzak with a
hint of gold to add visual warmth
W = Gloss White Paint
MW = Matte White
K (Cognac) = Warm copper color, specular Alzak
KH (Cognac Haze) = Cognac, semi-specular Alzak
GP Graphite = Gunmetal grey, specular Alzak
GPH Graphite Haze = Graphite, semi-specular Alzak
Baffle Options
BB =Black Baffle
WB = White Baffle
Flanges
Blank = Matte white die-cast flange ring, removable
for field painting
RAW = Die cast trim ring, mill finish
SF = Self Flange (flange color matches reflector cone)
SFWF = Self Flange painted Matte White
E5PIN
Blank = Matte White painted die-cast trim ring with
black oculus (when present)
W = Matte White painted die-cast trim ring with white
oculus (when present)
ELEMENT OPTIONS
Example:
E5T
Cone
Finish
Flange
Type
Finish
Example:
E5A19
Baffle
Finish
Flange Type and
Finish (self flange
not available)
Example:
E5PIN
Flange Type and
Finish (self flange
not available)
