SKU 90300 For technical questions, please call 1-800-444-3353. PAGE 2
PRODUCT SPECIFICATIONS
Item Description
Electrical Requirements 4,500W Maximum Output; 4,000W Continuous Output
20 AMPs @ 120V / 20 AMPs @ 240V
60 Hz Output
120V Dual Outlet: 20 AMP, 3 Prong Grounded
120/240V Outlet: 20 AMP, 4 Prong Twistlock (L14-20)
Overload Protection: Two 20 AMP Circuit Breakers
Battery Type Required: 12V with at least 24Ah capacity (not included)
Battery Size Capacity: 8" L x 5-1/4" W x 7-1/2 to 8" Tall
Engine Type 9 HP Robin
®
/Subaru
®
EX Series with Electric Start
4 Cycle / 265 CC Displacement
Model #EX-27052020
Alternator Two Pole / Single Phase / 60 Hz
Fuel Tank 6.5 Gallon
Estimated Run Time 14.5 Hours (w/ Full Tank @ 1/2 Load)
Overall Dimensions 29-3/4” x 25-1/2” x 20-5/8”
Weight 155 Pounds
THIS GENERATOR
IS NOT INTENDED TO POWER
SENSITIVE ELECTRONIC
EQUIPMENT WITHOUT THE
ADDITION OF AN APPROPRIATE
LINE CONDITIONER (SOLD
SEPARATELY).
REV 12/03; 02/04; 05/04; REV 03/06
This product requires oil and fuel to be added before starting.
Attempting to start the engine without oil WILL ruin the engine and
void the warranty.
Fill the engine with the following:
1.15 qt. of SAE 15W/40 oil
6.5 Gal. of unleaded gasoline with no oil added
Before starting the engine, refer to the engine owner’s manual for additional engine
maintenance information.
SAVE THIS MANUAL
You will need this manual for the safety warnings and precautions, operating, in-
spection, maintenance and cleaning procedures, parts list and assembly
diagram. Keep your invoice with this manual. Write the invoice number on the inside
of the front cover. Keep this manual and invoice in a safe and dry place for future
reference.
UNPACKING
When unpacking, check to make sure all the parts shown on the Parts List on page 18 are
included. If any parts are missing or broken, please call Harbor Freight Tools at the number
shown on the cover of this manual as soon as possible.
Call Harbor Freight Tools at 1-800-444-3353
for all technical questions and all inquires
regarding GENERATOR AND ENGINE
replacement parts.
