Hood, Grille & Dash Group
Footnotes:
TP 400-5063-1-TC-N
Manual No. 7006456GARDEN TRACTOR ELECTRIC CLUTCH
SERIES 0
7
Part No Descri
p
tionItem Qt
y
Note
1 1728031D 1 HOOD, W/Scoop
4 1721804D 1 PANEL, R.H. Side
5 1721803D 1 PANEL, L.H. Side
6 1721810 1 HEADLIGHT ASSEMBLY (Includes Ref. Nos. 22, 23 & 24)
7 1721802D 1 GRILLE
8 1930641 12 NUT, Hex Flange 1/4-20 Whiz Lock
9 1726827 1 DASHBOARD (Used only on YT & LT models)
10 1726894 1 DASHBOARD, W/Hydraulic Lift Slot (Used only on GT models)
12 1721808A 1 HINGE, Hood L.H.
13 1721809A 1 HINGE, Hood R.H.
14 1723123 1 ROD, Dash Support
15 1933896 1 NUT, Hex Lock 10-24 w/Nylon Insert
16 1960392 1 SCREW, Pan Head Phillips #10-24 x 1
17 1960295 12 SCREW, Hex Whiz Lock Flange 1/4-20 x 5/8
18 1733457A 1 DUCT, Air Inlet
19 1726895 1 DASHBOARD, w/Buzzer Hole (Used only on Barons models)
20 1722285 1 COVER, Dash (Used only on Barons models)
21 1722607 1 SCREW, Pan Head Torx #8-16 x 1/2 Plastite (Used only on Barons models)
22 1677371 4 BULB, Headlight
23 1723451 4 SOCKET ASSEMBLY, Seal
24 1722902 1 REFLECTOR, Headlight
