Installation
Instructions
HN-400
Barrier-Free Column Shower
P.O. Box 309, Menomonee Falls, WI 53052-0309
TEL: 1-800-BRADLEY FAX: (262) 251-5817
http://www.bradleycorp.com
Table of Contents
Pre-Installation Information . . . . . . . . . . . . . . . .2
HN-200 Column Shower Components
and Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . .2
Installation Instructions
Type A Column Shower . . . . . . . . . . . . . . . . . .3
Supplies from Below/Vent Off Line
Type B Column Shower Installation . . . . . . . .4
Supplies from Above/Vent Through Column
Type H Column Shower Installation . . . . . . . .5
Supplies from Below/Vent Through Column
Type O Column Shower Installation . . . . . . . .6
Supplies from Above/Vent Off Line
Optional Shroud Installation . . . . . . . . . . . . . . . .7
Cleaning Instructions . . . . . . . . . . . . . . . . . . . . .9
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
IMPORTANT:
Before beginning installation, all supply, drain and waste
piping to the shower must be completed according to the
rough-ins received with the drain assembly.
Check the local codes and ordinances in your area for
proper location and connection requirements. Conformity
to local codes is the responsibility of the installer.
Read and save this installation manual, which contains
maintenance and repair information, for future reference.
215-781; Rev. D; EN 03-310
© 2003 Bradley Corporation
Page 1 of 9 12-16-2003
