SPECIFICATION SHEET
REFERENCE QTY. REMARKS Project
Location
Architect
Engineer
Contractor
Submitted by Date
Best by Broan, P.O. Box 140, Hartford, Wisconsin 53027
IN-LINE BLOWERS
MODELS ilb9 & ilb11
Powerful yet quiet blowers - exhaust the cooking area
from a remote location.
FEATURES
BLOWER:
Low RPM for quiet operation
Resilient anti-vibration mounts
Dynamically-balanced, galvanized steel, centrifugal
blowerwheelforquiet,efcientperformance
Permanently lubricated, thermally protected motor
Plug-in motor rated at 120 VAC
Designed for continuous operation
HOUSING:
Rugged galvanized steel
8-position mounting brackets for easy installation and
greater adaptability to various mounting requirements
Automatic backdraft damper located within exhaust
duct connector
Factory-shipped in horizontal discharge position
May be converted to vertical discharge
Suitable for kitchen installations
ACCESSORIES INCLUDED:
8-inch x 12-inch integrated duct connectors
Two (2) 8-inch x 12-inch to 10-inch-round transitions
• Hangerkit-foradditionalinstallationexibility
Range hood rough-in kit with integrated 10-inch duct
connector
TYPICAL SPECIFICATION
In-Line Blower shall be Best by Broan Model ILB9, (ILB11).
Unit shall have galvanized steel housing. Housing to have
adjustable mounting brackets.
Blower to include hanger kit, two (2) 8-inch x 12-inch to 10-inch-
round transitions, 8-inch x 12-inch integrated duct connectors,
and a range hood rough-in kit with integrated 10-inch duct
connector.
Automatic backdraft damper to be located within exhaust duct
connector. Duct connectors, blower assembly and wiring plate
shall be adjustable for either horizontal or vertical installation.
Blower unit shall be removable from housing and will have a
galvanized steel, centrifugal-type blower wheel. Motor to be
permanently lubricated and mounted with resilient anti-vibration
mounts.
Air delivery shall be n o less than listed for each model. All
airratingsshallbecertiedbyHVI.UnitstobeULandcUL
listed.
70E 99043710D
* Performance ratings include the addition of a 10” round transition
on inlet and outlet.
SPECIFICATIONS
Model Volts Hz Amps CFM Duct Weight
ILB9 120 60 3.0 700 (V) 8” x 12” * 75.8 lbs.
800 (H)
ILB11 120 60 5.0 1000 (V) 8” x 12” * 75.9 lbs.
1100 (H)
HVI-2100 CERTIFIED RATINGS comply with new testing
technologies and procedures prescribed by the Home Ventilating
Institute, for off-the-shelf products, as they are available to
consumers. Product performance is rated at 0.1 in. static
pressure, based on tests conducted in AMCA’s state-of-the-art
test laboratory. Sones are a measure of humanly-perceived
loudness, based on laboratory measurements.
8” x 12”
DUCT CONNECTOR
