20-60x80mm
ELITE
®
Spotting Scope
Model # 61-0080
Eyepiece
Peep Sight
Focus Knob
Objective Lens
Tripod Mount
Power
Change Ring
Retractable
Sunshade
This photograph is a guide to the nomenclature and location of the ELITE
®
Spotting Scope
parts mentioned through this text.
Lit. #: 91-0097/03-01
Congratulations on your purchase of a Bausch & Lomb
®
ELITE
®
Spotting Scope!
•
The 80mm ELITE
®
is one of the finest, most versatile prismatic
spotting scopes in the world.
•
The 80mm ELITE
®
with ED Glass (Extra Low Dispersion Glass) provides
dramatic improvement in color correction with increased contrast
and resolution.
•
The 80mm ELITE
®
is fully multi-coated, providing increased
light transmission.
•
The 80mm ELITE
®
contains a waterproof body.
•
The 80mm ELITE
®
comes with a rugged carrying case that can
remain on the spotting scope during viewing.
•
The 80mm ELITE
®
is constructed of the finest materials and
assembled by highly skilled craftsmen to the highest quality standards.
MOUNTING
The ELITE
®
Spotting Scope tripod mount provides a convenient means
of fastening to any tripod, car window mount or other stable
platform. For best results, mount your ELITE
®
Spotting Scope on a firm
support to prevent any movement of the spotting scope. Movement
will make the viewed scene appear to vibrate at high magnification.
A firm mount will also help you to locate, track and keep objects in
the field of view.
ZOOM EYEPIECE
Align the white dot on the front of the eyepiece with the peep sight
on the spotting scope body. Insert the eyepiece and turn clockwise
until the white eyepiece dot and the peep sight are aligned.
FOCUSING
The ELITE
®
Spotting Scope will focus from 16 feet to infinity at any
power. Rotate the focus knob until you see a precise defined image.
The depth of field (the distance over which the image is seen in sharp
focus) and the field of view are greatest at lower powers. With the
zoom eyepiece, if the initial focusing is done at low power, you may
find that additional focus adjustment is required as power is increased.
SIGHTING
Your ELITE
®
Spotting Scope is equipped with a “peep sight”. Look into
the rear aperture located just above the eyepiece. Center the object
of interest in the field of view and look through the eyepiece.
Minimum adjustment will be required to center the object when
viewed through the eyepiece.
USE WITH EYEGLASSES
The ELITE
®
eyepiece is designed to provide you with the longest
practical eye relief possible. (Eye relief if the distance from the eye to
the eyepiece at which a full field of view is seen.) This provides you
with the same field of view with or without eyeglasses.The ELITE
®
eyepiece is equipped with a rubber eyeguard to eliminate the
possibility of scratching plastic eyeglass lenses.
CHANGING POWER
The variable power zoom eyepiece provides a 20x to 60x power range.
To change the magnification grasp the eyepiece body and rotate the
Power Change Ring to the desired power as indicated by the
Magnification Ring. As you zoom from low power to high power
under low light conditions, you may notice a decrease in the
image brightness. This is normal. As magnification is increased, the
amount of light transmitted to your eye, image brightness is
decreased proportionately.
SPECIFICATIONS
Field of View (@ 1000 yds.): 98’ @ 20x
50’ @ 60x
Exit Pupil: 4.1mm @ 20x
1.4mm @ 60x
Eye Relief: 15.5 @ 20x
16.5 @ 60x
For more information on tripods, car window mount and other Bausch &
Lomb
®
and Bushnell
®
Sports Optics Visit Our Website at www.bushnell.com
Bausch & Lomb is a registered trademark of and used under license from
Bausch & Lomb Incorporated
LIFETIME LIMITED WARRANTY
Your Bausch & Lomb
®
spotting scope is warranted to be free of defects
in materials and workmanship for the lifetime of the original owner.
The Lifetime Limited Warranty is an expression of our confidence in the
materials and mechanical workmanship of our products and is your
assurance of a lifetime of dependable service. In the event of a defect
under this warranty, we will, at our option, repair or replace the
product, provided that you return the product postage prepaid. This
warranty does not cover damages caused by misuse or improper
handling, installation or maintenance of the product.
Any return made under this warranty
must be accompanied by the items listed below:
1) A check in the amount of $10.00 to cover the cost of handling
2) Name and address for product return
3) An explanation of the defect
4) Product should be well packed in a sturdy outside shipping
carton to prevent damage in transit and return postage
prepaid to the address listed below:
IN U.S.A. Send To:
Bushnell Performance Optics
8500 Marshall Drive
Lenexa, Kansas 66214
For products purchased outside the United States and Canada please
contact your local dealer for applicable warranty information. This
warranty gives you specific legal rights. You may have other rights
which vary from country to country.
Bausch & Lomb
®
is a registered trademark of and used under license from
Bausch & Lomb Incorporated.
©2001 Bushnell Performance Optics
IN CANADA Send To:
Bushnell Performance Optics
25A East Pearce Street, Unit 1
Richmond Hill, Ontario L4B 2M9
