B1
© 2008 AS America Inc.
UPGRADABLE
PRESSURE BALANCE BATH/SHOWER FITTING
TEMPERATURE CONTROL VALVE
MODEL NUMBER:
R110 Pressure Balance Rough Valve Body only
Direct sweat inlets/outlets. LESS trim.
R110SS Pressure Balance Rough Valve Body only
with Screwdriver stops
Direct sweat inlets/outlets. Screwdriver stops. LESS trim.
R115 Pressure Balance Rough Valve Body only
Female thread inlets/outlets. LESS trim.
R115SS Pressure Balance Rough Valve Body only
with Screwdriver stops
Female thread inlets/outlets. Screwdriver stops. LESS trim.
R117 Pressure Balance Rough Valve Body only
PEX inlets/Direct sweat outlets. LESS trim.
R117SS Pressure Balance Rough Valve Body only
with Screwdriver stops
PEX inlets/Direct sweat outlets. Screwdriver stops. LESS trim.
PRODUCT FEATURES:
Cast Brass Valve Body: Durable - Quality that will last a
lifetime. Ideal material for prolonged contact with water.
Ceramic Disc Valve Cartridge: Assures a lifetime of
drip-free performance. Allows easy fine tuning of temperature
(125˚handle rotation from off to hot).
Pressure Balancing Valve Cartridge: Maintains constant
output temperature in response to changes in hot and cold
supply pressure. Diaphragm system engineered to eliminate
cross flow. Avoids failure due to mineral deposits - ideal for use
in hard water
Back-to-Back Capability: Hot and cold can be reversed
quickly and easily.
Adjustable Hot Limit Safety Stop: Limits the amount of
hot water allowed to mix with cold. Reduces the risk of
accidental scalding.
Exclusive Plaster Guard: Plaster guard is designed to
protect valve during installation and serve as a mounting plate
for thin-wall installations. 2 piece design allows valve to be
tested prior to trim installation.
Wide Rough-in Range: From 1-5/8" to 3-1/4".
SUGGESTED SPECIFICATION:
Bath/shower fitting shall feature a cast brass body. Shall feature ceramic disc valve cartridge which is capable of back-to-back
installation. Fitting shall be equipped with pressure balancing cartridge engineered to eliminate cross flow and avoid failure due to
mineral deposits. Shall also feature hot limit safety stop. Fitting shall be: Rough Valve Body - American Standard Model #
R11____, Trim Kit - American Standard Model # ____.____.
GENERAL DESCRIPTION:
Cast brass body, washerless ceramic disc valve cartridge
with back-to-back capability and hot limit safety stop. Cycles
from "off" to "cold" to "hot". Pressure balancing cartridge
maintains constant output temperature in response to
changes in relative hot and cold supply pressure. One-half
inch inlets and outlets (choice of direct sweat, threaded, or
PEX). Available with screwdriver stops. Rough-in plaster
guard designed for use as thin-wall mounting adaptor. Valve
body will accept a variety of decorative Bath/Shower trims.
FINISHED
WALL
TOP OF
TUB RIM
BOTTOM
OF TUB
1/2"
NPT
1/2"
COPPER
SHR.
1/2" NOM.
COPPER
SWEAT
TUB 1/2" NOM.
COPPER SWEAT
SHR.
1/2" NOM.
COPPER
SWEAT
TUB 1/2" NOM.
COPPER SWEAT
THREADED (STOPS) (R115SS)
PEX (STOPS) (R117SS)
103 mm
(4-1/16")
52 mm
(2-1/32")
104 mm
(4-1/16")
INLETS 1/2" NPT
1/2" PEX INLETS
(ASTM F1807)
149 mm
(5-7/8")
165mm
(6-1/2")
THREADED (R115)
INLETS
86 mm
(3-3/8")
INLETS
1/2" NPT
86 mm
(3-3/8")
SHR
1/2" NPT
TUB PORT
1/2" NPT
INLETS
103 mm
(4-1/16")
103 mm
(4-1/16")
INLETS 1/2" NOM.
COPPER SWEAT
SHR. 1/2" NOM.
COPPER SWEAT
TUB 1/2" NOM.
COPPER SWEAT
51.5 mm
(2-1/32")
51 mm
(2")
SHR. 1/2" NOM.
COPPER SWEAT
TUB 1/2" NOM.
COPPER SWEAT
SWEAT (STOPS) (R110SS)
SWEAT (R110)
VALVE BODY OPTIONS
103 mm
(4-1/16")
INLETS
1/2" NPT
149 mm
(5-7/8")
See reverse for available trim kits.
R110 Valve Body Shown
Ho
t
C
o
ld
O
ff
Available Trim Kits
Colony
Enfield
Hampton
Town Square
Amarilis
Tropic
Dazzle
Standard
One
O
f
f
Ho
t
H
OF
F
R110
Direct
Sweat
Inlets/
Outlets
R115
Female
Thread
Inlets/
Outlets
R117
PEX
Inlets/Direct
Sweat
Outlets
R115SS
Female Thread
Inlets/Outlets
w/ Screwdriver
Stops
R110SS
Direct Sweat
Inlets/Outlets
w/ Screwdriver
Stops
R117SS
PEX
Inlets/Direct
Sweat Outlets
w/ Screwdriver
Stops
VALVES
Valve + Trim: Trim Kit & Valve Body Packaged Separately
To order: Specify valve body and trim kit desired
Example: R110 - Direct Sweat Valve Body
T215.710 - Hampton Bath/Shower Trim Kit (Porcelain Lever Handle)
**** AMARILIS
trim kits are less handles--must be ordered separately.
the following handle kits are available:
** HAMPTON
available with choice of three handles.
to order: specify the three digit handle number
ex) T211.710 (valve only trim kit w/ porcelain lever handle)
* COLONY with 2.5 showerhead with FloWise
®
showerhead
NOTES:
*** ENFIELD available with lever or cross handle
T345.000
T342.000
T341.000
B/S
Shower
Valve
TRIM KITS
*
**
T375.XXX
T372.XXX
T371.XXX
T038.502
T038.501
T038.500
T215.7XX
T212.7XX
T211.7XX
T028.502
T028.501
T028.500
T6181
T6180
T6179
T064.502
T064.501
T064.500
T373.5X2
T373.5X1
T373.5X0
T555.502
T555.501
T555.500
***
1880mm
(74")
FOR HEAD
CLEARANCE
41mm TO 83mm
(1-5/8" TO 3-1/4")
457mm
(18")
OPTIONAL
25mm
(1")
102mm
(4") REF.
SHR.
1/2" NOM.
COPPER
SWEAT
TUB 1/2" NOM.
COPPER SWEAT
PEX (R117)
52 mm
(2-1/32")
104 mm
(4-1/16")
1/2" PEX INLETS
(ASTM F1807)
109mm
(4-1/4")
