ACRYLUX
™
38" x 38" CORNER SHOWER KIT
ACRYLUX 38" x 38" CORNER SHOWER KIT
Shower Kit With Walls:
❑ 3838Y1K.DT Shower Kit With Walls
Includes the following components:
Shower Base Features:
• 3838Y1.DT Shower Base
• High-gloss acrylic-capped ABS with
berglass reinforcement
• Double threshold with tiling ange
Nominal Dimensions:
38" x 38" x 5-1/8"
(965 x 965 x 130mm)
Door Features:
• 3838Y1.DTE5.213 Bath Door
• Two sliding tempered safety glass panels
• Silver Shine frame nish
• Rain privacy glass
Centerline Dimensions:
35-1/2" x 35-1/2" x 72"
(902 x 902 x 1829mm)
Wall Set Features:
• 3838Y1.CWT Bath Tile Wall Set
• High-gloss acrylic-capped ABS with
berglass reinforcement
• Mounts directly to studs
• Caulk-less installation
Nominal Dimensions:
72" tall x 38" wide
(1829 x 965mm)
Shower Kit Without Walls:
❑ 3838Y1KB.DT Shower Kit Without Walls
• Same as above but without wall set
Compliance Certications -
Meets or Exceeds the Following Specications:
• ANSI Z97 for Safety Glazing Materials
• ANSI Z124.1.2 for Plastic Bathtubs and Shower Units
• ASTM E162 for Flammability
• NFPA 258 for Smoke Density
72"
(1829mm)
38"
(965mm)
1"
(25mm)
5-1/8"
(130mm)
39-1/2"
(1003mm)
39-1/2"
(1003mm)
38"
(965mm)
38"
(965mm)
STUD LAYOUT
6"
(152mm)
Floor Cutout
18"
(457mm)
10"
(254mm)
18"
(457mm)
= Stud Location
Revised 10/08
