F101
© 2008 AS America Inc.
Description
Model #
Finishes
Roughing-In Dimensions
FINISHED WALL
38mm
(1-1/2)
1660.125
“TREVI” DELUXE ADJUSTABLE
BODY SIDE SPRAY
• Self Cleaning Patented Design:
Flexible ring with spray holes prevents
lime scale build up.
• Spray Pattern: Variable spray
adjusts from a conventional spray to a
massage action.
• Simple Spray Adjustment: Spray
position adjusts up to 20˚ in any
direction.
• Flow Restrictor: 2.5 gpm/9.5L/min.
.002 Polished Chrome
.008 Polished Nickel
.068 Blackened Bronze (PVD)
.075 Stainless Steel (PVD)
.099 Polished Brass (PVD)
.295 Satin Nickel (PVD)
2-1/4
(56mm)
DIA.
3 - 3-1/2
(75-89mm)
40°
SHOWER SYSTEMS
BODY SIDE SPRAY
